C.023.050.0160.A
€1.27
In stock
Details
- Product Name: C.023.050.0160.A
- Wire Diam. (mm): 0.5
- Ext. Diam. (mm): 2.3
- Internal Diameter (mm): 1.3
- Nr of Coils: 23.8
- Free Len. (mm): 16
- Pitch (mm): 0.68
- Shaft (mm): 1.274
- Length @max load (mm): 13.45
- Spring Rate (daN/mm): 0.5
- Block Length(mm): 12.15
- Hole (mm): 2.346
- Buckling at length (mm): 13.65
- Weight (g): 0.208844
- Endurance: 10000000
- Grinding: 1
- Material: Music Wire
| Product Name | C.023.050.0160.A |
|---|---|
| Wire Diam. (mm) | 0.5 |
| Ext. Diam. (mm) | 2.3 |
| Internal Diameter (mm) | 1.3 |
| Nr of Coils | 23.8 |
| Free Len. (mm) | 16 |
| Pitch (mm) | 0.68 |
| Shaft (mm) | 1.274 |
| Length @max load (mm) | 13.45 |
| Spring Rate (daN/mm) | 0.5 |
| Block Length(mm) | 12.15 |
| Hole (mm) | 2.346 |
| Buckling at length (mm) | 13.65 |
| Weight (g) | 0.208844 |
| Endurance | 10000000 |
| Grinding | 1 |
| Material | Music Wire |
